Medical Tablet

Easy, efficient access to the information you need

You need to make efficient, informed decisions about patient care. The speed and ease with which you can view information from different sources can make a real difference. This is the vision behind the Philips Medical Tablet, a practical device that can connect over wired, wireless, clinical or non-clinical networks. You can access relevant patient information on the go. This product is distributed by Philips.

Safe for use in isolation scenarios

Easily integrated with internal program

Transport monitor compatible

Features

Running widely-accepted operating system allows for flexibility

Because the tablet runs on the Windows 10 operating system, you can use it to create a flexible resource combining patient monitoring and your hospital’s third-party information, such as medical records, lab results, or PACS. Access can even be simplified, standardized and customized using XDS LaunchPad.

Designed to withstand frequent use in patient care areas

The Philips Medical Tablet is designed to withstand knocks and is resistant to water as well as cleaning and disinfection materials. As well, the Medical Tablet has been tested to meet standard safety requirements for use near patients.

A flexible companion screen for your IntelliVue monitor

Running IntelliVue XDS Software¹ allows the Medical Tablet to be used as an independent display for any IntelliVue monitor. This might be to display clinical decision support tools such as Advanced Event Surveillance, or to support specific information needs such as a 12-lead ECG layout or ST MAP without interrupting the overall view of vital signs displayed on the monitor. The Medical Tablet running XDS Software can also be used to complement a smaller or transport monitor such as an IntelliVue X3 or MX100 monitor in post-operative care or step-down units. The Medical Tablet can boost monitor visibility, display more of the measured parameters, or simplify operation with the larger screen.

Specifications

Physical Specifications
Display size
25.65 cm (10.1 in) LCD
Display resolution
1290 x 800
Display type
Capacitive multi-touch panel
Memory
4 GB RAM; 128 GB solid-state drive
Camera
2 MP front camera; 8 MP rear camera
Weight
1 kg (2.2 lb), including battery
Operating system
Window 10 operating system
Screen navigation
Touchscreen/Mouse
Touchscreen
Battery
Capacity
28.44 W Li-ion; 8-hour operating time (depending on use); comes with a +19 V 60 W charger
Operating time
7-hour operating time (4 hours with XDS running continuously)
Networking
Networking capability
WLAN 802.11 a/b/n/g/ac; Bluetooth 4.1; NFC
Ruggedness
Ingress protection
Dust-tight, and protected against splashing and water jets (IP65), and cleaning/disinfection agents
Construction
Rubber and plastic: withstands 1.2 m (4 foot) drop on concrete floor (MIL-STD-810G)
Electrical/electromagnetic safety
Fulfills the electrical safety (IEC 60601-1-1) and EMC standards (IEC 60601-1-2)

Documentation

Philips Medical Tablet product brochure

PDF|882.53 KB
